Report
This report is an archived publication and may contain dated technical, contact, and link information
Publication Number: FHWA-HRT-04-150
Date: July 2006

Chapter 11. Cementitious Materials

Previous | Table of Contents | Next

11.1 OVERVIEW

The concrete petrographer is often called upon to ascertain the presence or absence of particulate materials other than portland cement in a specimen of HCC. These materials include all of the finely comminuted solid substances that may be added to HCC to improve its properties or reduce its cost. These substances are of relatively small grain size, usually at least as small as that of portland cement. Included are pulverized limestone (Kleiger and Hooton, 1988), hydrated lime, natural pozzolans, fly ash, slag, and silica fume (see ACI 232.1R, 232.2R, 233R, and 234R; Cain, 1994; TRB, 1990).

In general, when these materials have been used in a concrete mixture as prescribed, the resulting concrete has higher ultimate strength and is less permeable than a similar concrete that does not include these materials. Historically, some of these substances were considered to be adulterants and their use was considered to be an effort to dilute the cement and produce a less costly, less energy-intensive product (e.g., ground limestone). However, materials such as ground slag or pozzolans improve key HCC properties that directly impact durability. A potential drawback to their use when the mixture is not proportioned properly is delayed strength gain (except with silica fume and other high-fineness pozzolans). In cold weather, this delay can be sufficient to mandate against their use.

These materials should not be considered as adulterants when they have been specified for use. The particulate materials that are rich in amorphous silicates (slag, fly ash, silica fume, and natural pozzolan) are hydraulic (slag) or pozzolanic and will combine with the calcium hydroxide of HCC to form silicate hydrates that are cementitious and indistinguishable from the hydrated products of portland cement. The reaction of these materials cause the sequestration of deleterious alkalis in nonswelling silicate hydrates (see appendix D) that are widely disseminated throughout the paste. Thus, these pozzolanic materials prevent the deterioration that might be caused by the AARs provided that they are used in sufficient amounts.

The fine grain size; slow hydration; and, in some cases, particular particle shape add desirable properties to HCC. The heat of hydration is generated more slowly and, therefore, the temperature of the HCC does not rise so high. One of the most important desirable properties conferred by these materials is the decreased permeability of the resulting HCC. The decreased permeability is not only desirable in and of itself, it also decreases the movement of solutions and the diffusion of ions and thus any chemical activity, such as that of alkali reactivity or the activity of invasive deleterious substances such as chlorides. Pozzolanic materials are reported to be effective in increasing the acid resistance of concrete (Cain, 1994). Natural pozzolans and fly ash should comply with the requirements of ASTM C 618, slag with ASTM C 989, and silica fume with ASTM C 1240. Pozzolans and slag may also be used as components in hydraulic cements covered by ASTM C 595 and ASTM C 1157.

The appearance of a mature concrete in which these materials have been used is generally that of concrete with a low w/cm (see chapter 9). Pulverized limestone, cement kiln dust, or hydrated lime may be suspected in HCC that appears to have the texture of an HCC with a low w/cm and numerous minute particles of high birefringence when viewed in thin sections with crossed 182 polarized light using a petrographic microscope. It is impossible to be certain with mature concrete and without any magnification if fly ash, slag, or silica fume is present or if the paste characteristics are solely a result of a low w/cm.

11.2 PROCEDURES

Detecting the presence of pozzolans or slag in HCC is dependent on the characteristics of the particular material, as discussed here. The presence of fly ash or slag can sometimes be established in hand specimens, whereas establishing the absence of the material or estimating its relative proportion requires more detailed examination of specimens using the petrographic microscope (chapters 12 and 13) or SEM (see chapter 14). Hooton and Rogers (1995) describe quantitative techniques for estimating the percentage of slag and fly ash in HCC by examination of thin sections and XRD analyses. Schlorholtz and Dubberke (1995) used XRF to measure trace elements (Ba and Sr, in this case) to estimate fly-ash content.

As mentioned in chapter 2, reference samples of the common cementitious materials encountered should be maintained in the laboratory for preparation of immersion mounts and thin or polished sections as described in sections 5.4 or 14.3.3. These specimens are examined in either transmitted light (immersion mounts and thin sections) as discussed here or with the SEM (thin and polished sections) as discussed in chapter 14.

11.2.1 Cementitious Powders

This is a one-step procedure:

Examine the specimens and describe the particles present: Portland cement is a multiphase material consisting of four major clinker minerals and sulfate. Campbell (1986, 1999) provides an excellent discussion of the microscopic characteristics of portland cements. Figures 132 and 133 show alite (C3S) and belite (C2S) in an immersion mount of portland cement. Crystal morphology and birefringence are keys to identifying the phases in cements and distinguishing them from pozzolans and ground slag. Ground slag and pozzolans are characterized by particle size, shape, and isotropic optical properties resulting from their amorphous nature. Figures 134 through 137 illustrate fly ash (low lime, class F), silica fume, calcined shale natural pozzolan (class N), and ground slag. In crossed polarized light (not shown), the slag and silica fume demonstrate their amorphous character by an essentially total lack of birefringent grains. The bulk of fly ash and natural pozzolans should be amorphous; some crystalline grains exhibiting low birefringence are usually observed. These materials can also be observed using the SEM (chapter 14) where the higher resolving power is particularly useful because of the small particle sizes. In figure 138, SEM images of portland cement, fly ash, an ultrafine fly ash, and silica fume contrast the difference in particle size of these materials.

Figure 132. Immersion mount of portland cement in plane polarized light showing alite crystals.

This image shows alite crystals. The only portion of these crystals that stands out clearly is their outline.

Figure 133. Immersion mount of belite cluster with darker interstitial aluminate and ferrite.

This image is of a belite cluster with darker interstitial aluminate and ferrite that stands out sharply.

Figure 134. Immersion mount of fly ash showing spherical particle shape.

The fly ash particles are spherical.

Figure 135. Immersion mount of agglomerate of minute ilica-fume particles.

The silica-fume particles are very small and agglomerated.

Figure 136. Immersion mount of natural pozzolan (calcined shale).

The natural pozzolan is about 35 micrometers on its longest dimension and has very dark spots. Other small particles are present as well.

Figure 137. Immersion mount of ground cement slag.

Slag particles are up to about 25 micrometers in longest dimension and appear rather translucent and glassy.

Figure 138. SEM images illustrating the size difference of various cementitious materials.

The four views include cement, fly ash, silica fume and ultra-fine fly ash. The cement particle has rough edges and measures about 15 micrometers in its longest dimension. The fly ash particles are essentially spherical with diameters ranging between 8 and 20 micrometers. The ultra-fine fly ash particles are also spherical with diameters ranging from a fraction of a micrometer to about 3 micrometers. Silica fume particles are smaller than 1µm and appear irregular shaped and somewhat agglomerated.

11.2.2 Hydraulic Cement Concrete

11.2.2.1 Ground Granulated Blast-Furnace Slag

This is a three-step procedure:

  1. Examine exterior surfaces, broken surfaces, and lapped slices of the HCC: When very young, the pastes containing slag are a characteristic dark bluish green. Mather (1957) investigated the reasons for this color in portland slag cements and concluded that the development of the color varies from cement to cement and is a result of the presence of sulfur compounds in a reduced state (sulfide), the color being lost on oxidation. Regardless of maturity, if these pastes are kept underwater and are not allowed to dry, they will retain this color. As the concrete begins to dry, the surface color fades. If the HCC is sawed or broken while it is only partially dry, it can be seen to be mottled with dark and light places. When it is dry throughout, it will be a uniform light color (see figures 139 and 140). This color is not the same color as ordinary HCC. It is not a gray

    Figure 139. Cut surface on HCC containing slag exposed to air for 6 months.

     In this view, the paste is of a uniform color.

    1 inch = 25.4 mm

    Figure 140. Interior of beam of HCC containing slag, illustrating the partially dry two-color stage.

    In this view, the majority of the paste is dark greenish gray while a small section on the top is a lighter beige color.

    1 inch = 25.4 mm

    color, but rather a very light shade of slightly greenish tan or cream. The mottled appearance of an interior surface of slag-bearing concrete of intermediate age is often of concern to field personnel. It has often been thought that the mixing of the HCC was incomplete. In thin sections examined with the petrographic microscope, the dark-colored areas appear to be no different from the faded areas and both types of areas seem to have about the same concentration of slag. If slag was used in the mixture, this mottling is inconsequential and will fade. Slag cannot be detected in mature, fully dried concrete with the stereomicroscope.

  2. Examine several thin sections of the paste of the specimen with the petrographic microscope: Slag can be seen in thin sections and is quite distinctive in appearance. Unhydrated slag is primarily glass and, therefore, almost completely lacking in birefringence.
  3. Compare the view observed with the views in figures 141 through 143: If slag cannot be found by examination of the paste in a thin section, report that it was not detected in the specimen. Figures 141 through 143 illustrate the appearance of slag at three stages of hydration.
11.2.2.2 Fly Ash

This is a four-step procedure:

  1. Examine a lapped slice of the HCC with a stereomicroscope: Fly ash is usually of quite varied particle sizes, and the larger particles can be seen with the stereomicroscope. Most of the individual particles of fly ash approved for use in HCC are colorless to white. Some of the larger particles are hollow spheres (cenospheres). The walls of the cenospheres are frequently thin enough and the cenospheres are large enough to be mistaken for entrained air voids (see Walker, 1983). Sometimes, little dark (black or brown) balls of fly ash (sometimes hollow) can be seen; sometimes, agglomerations of fine fly-ash froth are present (see figure 78).
  2. To detect all of the particles of fly ash and to distinguish them from air voids, etch the slice or a portion of the slice, rinse, blot, allow to dry, and examine with the stereomicroscope (see section 5.2.3): Observe the acid-resistant glass walls of any flyash particles (see figure 144). These glass walls are very thin, but can be seen with lowangle illumination projecting above the paste that has been etched away. Air voids will not have such projecting walls.
  3. Examine thin sections with the petrographic microscope (see figures 145 and 146).
  4. If fly ash cannot be detected on an etched lapped slice and cannot be found in the thin section, report that it could not be found in the specimen.

Figure 141. Thin section of concrete containing slag: At 28 days hydration (note the angularity of the slag fragments).

Compare figures 141–143. In all the slag concentration is 65 percent of the cementitious material.

Concentration is 65 percent of cementitious material.

Figure 142. Thin section of concrete containing slag: At 56 days hydration (note the slight rounding of the slag fragments).

Compare figures 141–143. In all the slag concentration is 65 percent of the cementitious material.

Concentration is 65 percent of cementitious material.

Figure 143. Thin section of concrete containing slag: At 6 months hydration (note the further rounding of the slag fragments)

Compare figures 141–143. In all the slag concentration is 65 percent of the cementitious material.

Concentration is 65 percent of cementitious material.

Figure 144. Etched area of lapped surface of concrete containing fly ash.

Partial fly-ash particles are pointed out in the photo and categorized in three types. A frothy fly-ash agglomeration is hazy white. Cenospheres filled with froth or many cenospheres are small black circles. Cup shaped portions of cenospheres are white circles with black in the concave center.

The partial fly-ash particles are indicated by arrows. The particle at the starred arrow is a frothy fly-ash agglomeration. Nearly complete white cenospheres probably filled with froth or a multitude of smaller cenospheres are marked with a "W". These whole cenospheres have been almost completely exposed by the etching procedure; some small whole cenospheres may have been lost during the etching procedure. Cup-shaped portions of cenospheres are marked with a "C".

Figure 145. Fly ash in thin section of HCC, viewed in plane polarized light with a petrographic microscope (note the broken fly-ash particle that is composed of dark and light glass, 100X).

Photo. Fly ash in thin section of H C C, viewed in plane polarized light with a petrographic microscope (note the broken fly-ash particle that is composed of dark and light glass, magnified 100 times).

Figure 146. Fly ash in thin section of HCC, viewed in plane polarized light with a petrographic microscope (cenospheres of fly ash filled with smaller cenospheres, 400X).

Photo. Fly ash in thin section of H C C, viewed in plane polarized light with a petrographic microscope (cenospheres of fly ash filled with smaller circular cenospheres, magnified 400 times).
11.2.2.3 Silica Fume

Properly dispersed silica fume has such small particles and is so lacking in birefringence that its presence cannot be detected even in thin sections at 400X. Report that the presence of silica fume cannot be detected by the laboratory. Dry-densified silica fume that is not dispersed or is poorly dispersed will appear as small, dark gray to black particles in reflected light. In transmitted light, they will appear clear, extremely fine-grained, and isotropic. Undispersed silica-fume pellets can cause damage as a result of ASR. Laboratories that have the capability of examining specimens with a SEM can detect and photograph this material.
