EDC News

May 5, 2016

Innovation of the Month: 3D Engineered Models: Schedule, Cost and Post-Construction

The Every Day Counts (EDC) innovation of the month for May is 3D engineered models, which depict highway facilities in an accurate, easy-to-view way. After promoting this technology for design and construction in EDC-2, the Federal Highway Administration is encouraging states in EDC-3 to expand its use to other project delivery phases and add 4D and 5D to their modeling practices.

EDC-3 3D Engineered Models video
As a result, at least five states are using 3D models in post-construction and program-level applications, such as creating asset inventories and as-built records. Six states are exploring 4D and 5D modeling by adding schedule and cost data to 3D models to improve constructability and project management and provide more accurate cash-flow estimates.

Already, 25 states and Federal Lands Highway are deploying 3D engineered models for construction or planning to make it a standard practice. Three states—Iowa, Michigan and Missouri—have mainstreamed the practice.
Watch sessions in the 3D Engineered Models webinar series to learn more about 3D, 4D and 5D models.

Contact Chris Schneider of FHWA’s Office of Infrastructure or David Unkefer of FHWA’s Resource Center for information or technical assistance.

Illinois Signs Agreement on First Responder Training

Leaders of the Illinois State Police and Illinois Department of Transportation signed a revised joint operational policy agreement on April 19. The new agreement—which updates a 2004 agreement—fosters greater cooperation by clearly establishing each agency’s jurisdictional responsibilities. It strengthens the framework and components of traffic incident management responder training to prepare the state’s first responders to clear traffic incidents quickly and safely. It also clarifies public notification procedures for crashes and adverse weather conditions.

Kansas Makes Progress on Johnson County Gateway

The Kansas Department of Transportation continues to make progress on the Johnson County Gateway, the state’s first major design-build project. The project is designed to improve safety and relieve congestion on the I-435/I-35/K-10 interchange. The westbound I-435 to southbound I-35 flyover interchange ramp is open to traffic, and the eastbound to northbound ramp is set to open in mid-May. Construction on the $288 million project is scheduled for completion by the end of 2016.

The new diverging diamond interchange at I-35 and 95th Street means new ramps and a new configuration on the west side. Photo: Kansas DOT.
The new diverging diamond interchange at I-35 and 95th Street means new ramps and a new configuration on the west side. Photo: Kansas DOT

Missouri Shares e-Construction Experiences With Illinois

Representatives of the Missouri and Illinois Departments of Transportation conducted an e-Construction peer exchange on April 26. After Illinois DOT staff provided an overview of the agency’s vision to adopt paperless business practices over the next two years, Missouri DOT staff discussed the e-Construction technology it uses. A software demonstration by a Missouri DOT resident engineer provided a hands-on perspective of e-Construction on an active project.

Washington, D.C., Plans Neighborhood Bike Network

The District Department of Transportation and FHWA collaborated with the Royal Netherlands Embassy on a ThinkBike workshop April 21 and 22 in Washington, D.C. The workshop brought together Washington-area transportation planners, Dutch bicycle transportation experts and cyclists to design a bike network plan for a neighborhood in the nation’s capital. The group focused on intersection conflicts, bike parking and road diet options. ThinkBike workshops are designed to help U.S. communities improve bicycle infrastructure.

More EDC News »
