Cable-stayed bridge configurations have become more common over the past several decades for bridges in the medium- to long-span range. Nonetheless, in some cases, serviceability problems involving large-amplitude vibrations of stay cables under certain wind and wind–rain conditions have been observed. This study was conducted in response to State transportation department interest in developing improved design guidance for mitigation of excessive cable vibrations on cable-stayed bridges. The study included full-scale forced vibration tests on the cables of a new cable-stayed bridge to characterize the dynamic behavior of cables and evaluate the effectiveness of mitigation details such as crossties. The results of this study will be made available to the Post-Tensioning Institute's DC-45 Cable-Stayed Bridge Committee for consideration during periodic updates of their Recommendations for Stay Cable Design, Testing and Installation publication.
This report will be of interest to bridge engineers, wind engineers, and consultants involved in the design of cable-stayed bridges. It is the sixth in a series of reports addressing the subject of aerodynamic stability of bridge stay cables.
Cheryl Allen Richter, P.E., Ph.D.
Director, Office of Infrastructure
Research and Development
Notice
This document is disseminated under the sponsorship of the U.S. Department of Transportation (USDOT) in the interest of information exchange. The U.S. Government assumes no liability for the use of the information contained in this document.
The U.S. Government does not endorse products or manufacturers. Trademarks or manufacturers' names appear in this report only because they are considered essential to the objective of the document.
Quality Assurance Statement
The Federal Highway Administration (FHWA) provides high-quality information to serve Government, industry, and the public in a manner that promotes public understanding. Standards and policies are used to ensure and maximize the quality, objectivity, utility, and integrity of its information. FHWA periodically reviews quality issues and adjusts its programs and processes to ensure continuous quality improvement.
Technical Report Documentation Page
| 1. Report No.
FHWA-HRT-21-058 |
2. Government Accession No. | 3. Recipient's Catalog No. | ||
|---|---|---|---|---|
| 4. Title and Subtitle
Dynamic Properties of Stay Cables on the Leonard P. Zakim Bunker Hill Bridge |
5. Report Date
May 2021 |
|||
| 6. Performing Organization Code |
||||
| 7. Author(s)
Harold R. Bosch and James R. Pagenkopf (ORCID ID: 0000-0001-5392-8628) |
8. Performing Organization Report No. | |||
| 9. Performing Organization Name and Address
Genex Systems, LLC |
10. Work Unit No. | |||
| 11. Contract or Grant No.
DTFH61-13-D-00011 |
||||
| 12. Sponsoring Agency Name and Address
Office of Infrastructure Research and Development |
13. Type of Report and Period Covered
Laboratory Report; December 2003– |
|||
| 14. Sponsoring Agency Code
HRDI-40 |
||||
| 15. Supplementary Notes
The Contracting Officer's Representative was Harold R. Bosch (HRDI-40). |
||||
| 16. Abstract
Cable-stayed bridges have been recognized as the most efficient and cost effective structural form for medium- to long-span bridges over the past several decades. With their widespread use, cases of serviceability problems associated with large-amplitude vibration of stay cables have been reported. Stay cables are laterally flexible structural members with low inherent damping and thus are highly susceptible to environmental conditions such as wind and rain–wind combinations. |
||||
| 17. Key Words
Cable-stayed bridges, cables, vibrations, wind, rain, crossties, dampers, hazard mitigation |
18. Distribution Statement
No restrictions. This document is available through the National Technical Information Service, Springfield, VA 22161. |
|||
| 19. Security Classification (of this report) Unclassified |
20. Security Classification (of this page) Unclassified |
21. No. of Pages
184 |
22. Price
N/A |
|
| Form DOT F 1700.7 (8-72) | Reproduction of completed page authorized |
|---|
