REPORT |
This report is an archived publication and may contain dated technical, contact, and link information |
![]() |
Publication Number: FHWA-HRT-20-063 Date: December 2020 |
Publication Number: FHWA-HRT-20-063 Date: December 2020 |
PDF Version (2.76 MB)
Technical Report Documentation Page
1. Report No.
FHWA-HRT-20-063 |
2. Government Accession No. | 3 Recipient's Catalog No. | ||
4. Title and Subtitle
High-Level Concept of Operations: Examination of the Relationships Between Transportation Systems Management and Operations Strategies and Cooperative Driving Automation |
5. Report Date
December 2020 |
|||
6. Performing Organization Code | ||||
7. Author(s)
Sudhakar Nallamothu (ORCID: 0000-0002-7457-3704), John Stark (ORCID: 0000-0002-1558-4630), Elizabeth Birriel (ORCID: 0000-0002-8945-0715), Imran Inamdar (ORCID: 0000-0002-8395-2044), Nu Rosenbohm, Aafiya Shah (ORCID: 0000-0003-0731-0653), Joel Ticatch, Govindarajan Vadakpat (HRDO-20; ORCID: 0000-0001-9060-3216), and Taylor Lochrane (HRDO-10); (ORCID: 0000-0002-1933-6554) |
8. Performing Organization Report No. | |||
9. Performing Organization Name and Address
Leidos, Inc.
|
10. Work Unit No. (TRAIS) | |||
11. Contract or Grant No.
DTFH61-16-D00030 |
||||
12. Sponsoring Agency Name and Address
U.S. Department of Transportation |
13. Type of Report and Period Covered
Final Report; August 2018–August 2020 |
|||
14. Sponsoring Agency Code
HRDO |
||||
15. Supplementary Notes
Govindarajan Vadakpat (HRDO-20) and Taylor Lochrane (HRDO-10) were the Contracting Officer's Representatives. |
||||
16. Abstract
This report explores the relationships between transportation systems management and operations (TSMO) strategies and cooperative driving automation (CDA). It presents a high-level concept of operations (ConOps) in support of the CARMA PlatformSM sponsored by the Federal Highway Administration Office of Operations Research and Development. Developing this ConOps is an initial step in the current CARMASM effort to define and develop testable use cases that demonstrate how CDA capabilities can be integrated with TSMO strategies. The ConOps first discusses the traditional TSMO strategies for operating and managing the transportation infrastructure. It then identifies, at a high level, those strategies expected to be impacted by the introduction of CDA technologies. Next, from among this nexus of TSMO strategies, the ConOps focuses on four use cases–basic travel, traffic-incident management, road-weather management, and work-zone management–and explores the framework of those relationships in greater detail. The ConOps also describes whether–and, if applicable, how–CDA will impact existing TSMO use case activities. This mapping accounts for both the levels of vehicle automation and classes of vehicle cooperation. |
||||
17. Key Words
Transportation systems management and operations, TSMO, automated driving system, ADS, cooperative driving automation, CDA |
18. Distribution Statement
No restrictions. This document is available to the public through the National Technical Information Service, Springfield, VA 22161. |
|||
19. Security Classification (of this report) Unclassified |
20. Security Classification (of this page) Unclassified |
21. No. of Pages
128 |
22. Price
N/A |
Form DOT F 1700.7 (8-72) | Reproduction of completed page authorized |
