Report
This report is an archived publication and may contain dated technical, contact, and link information
Publication Number: FHWA-RD-03-065
Date: September 2004

In-Vehicle Display Icons and Other Information Elements: Volume I

PDF Version (8.33 MB)

PDF files can be viewed with the Acrobat® Reader®

Chapter 8

Icon Details by Icon Type

1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | 15 | 16 | 17 | 18

Function: Routing and Navigation

Trip planning

Attractions

Function: Routing and Navigation

Trip planning

General

Icon Message: Fastest route available Icon Message: Route avoiding tollways
Icon Message: Length of wait. Clip art of person sitting down with wall clock Icon Message: States, regions, communities, and districts along the route

Icon Message: Most scenic route

Icon Message: Transit schedules in areas along route. Clip art of bus

Icon Message: Number of traffic lights/stops of route options. clip art of trafficl light

Icon Message: Type of roads on route



Icon Message: Road end/bridge out. clip art of car falling into water





Function: Routing and Navigation

Trip planning

General

Function: Routing and Navigation

Trip planning

Lodging

Icon Message: Type of roads on route Icon Message: Price of lodging. Clip art of bed with dollar sign above it.

Function: Routing and Navigation

Trip planning

Lodging

Icon Message: Lodging

Icon Message: Restaurant/food ahead. Clip art of fork plate and knife

Icon Message: No vacancy. Clip art of house with beds in all rooms

Icon Message: Restaurant/food ahead. Clip art of fork and knife

Icon Message: Price of Lodging

Icon Message: Restaurant/food ahead. Clip art of fork and knife





Icon Message: Vacancy. Clip art of house with beds in all rooms except for one.
