Report
This report is an archived publication and may contain dated technical, contact, and link information
Publication Number: FHWA-RD-03-065
Date: September 2004

In-Vehicle Display Icons and Other Information Elements: Volume I

PDF Version (8.33 MB)

PDF files can be viewed with the Acrobat® Reader®

Chapter 8

Icon Details by Icon Type

1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | 15 | 16 | 17 | 18

Function: Motorist Services Information

Broadcast service/attractions

Business/service



Function: Motorist Services Information

Broadcast service/attractions

Business/service

Icon Message: Dry cleaning Icon Message: Pest Service (Clip art of a mice and a bug)
Icon Message: Food (clip art of fork and knife) Icon Message: Photo Copy (clip art of paper and zerox machine)
Icon Message: Hair Salon (clip art of scissors) Icon Message: Photo developing (clip art of roll of film)
Icon Message: House Cleaning (clip art of house, vacum and bucket) Icon Message: Plumbing/heating
Icon Message: Lawn Service ( clip art of hoseand lawnmower) Icon Message: Pool service (clip art of pool with diving board)



Function: Motorist Services Information

Broadcast service/attractions

Business/service



Function: Motorist Services Information

Broadcast service/attractions

Entertainment

Icon Message: Roof service (clip art of house and brick) Icon Message: Casino (clip art of casino cards)
Icon Message: Security (clip art of a key with lock) Icon Message: Casion (clip art of roulette machine)
Icon Message: Tailor (clip art of scissors and shirt) Icon Message:Casion (clip art of slot machine)
Icon Message: Amphitheater Icon Message: Live Music (clip art of singer and person playing drums)
Icon Message: Arts and culture venue (clip art of mask) Icon Message: Movie Theater



Function: Motorist Services Information

Broadcast service/attractions

Entertainment



Function: Motorist Services Information

Broadcast service/attractions

Entertainment

Icon Message: Movie Theater (clip art of film projecter) Icon Message: theater (clip art of theater masks)
Icon Message: Movie theater (film projecter) Icon Message: Theater (clip art of transparent masks)
Icon Message: Music venue Icon Message:Theater (clip art of transparent, comic masks)
Icon Message: Night life attraction
