Placement of Warm Mix Asphalt on the East Entrance Road of Yellowstone National Park

Previous Chapter « Table of Contents » Next Chapter

FHWA-WFL/TD-09-002
January 2009

Front Materials

• Cover
• Table of Contents
  • Figures
  • Tables



Technical Report Documentation Page

1. Report No. FHWA-WFL/TD-09-002	2. Government Accession No.			3. Recipient's Catalog No.
4. Title and Subtitle Placement of Warm Mix Asphalt on the East Entrance Road of Yellowstone National Park				5. Report Date January 2009
				6. Performing Organization Code
7. Author(s) Brad Neitzke and Bruce Wasill				8. Performing Organization Report No.
9. Performing Organization Name and Address HK Contractors, Inc. P.O. Box 51450 Idaho Falls, ID 83405				10. Work Unit No. (TRAIS)
				11. Contract or Grant No.
12. Sponsoring Agency Name and Address Federal Highway Administration Western Federal Lands Highway Division 610 East 5th St. Vancouver, WA 98661 National Park Service Yellowstone National Park P.O. Box 168 Yellowstone National Park, WY 82190-0168				13. Type of Report and Period Covered Final Report 2009
				14. Sponsoring Agency Code HFL-17
15. Supplementary Notes This technology deployment was funded under the FHWA Federal Lands Highway Coordinated Technology Implementation Program (CTIP).
16. Abstract In an eff ort to deploy the warm mix asphalt (WMA) technology to Federal Lands Highway (FLH) and cooperating agencies, a Coordinated Technology Implementation Program (CTIP) proposal was approved by agency representatives. This CTIP project allowed FLH to take the lead in working with our client agency and contractors to evaluate the viability of warm mix technology as a standard construction practice. The demonstration evaluated two different WMA technologies (Advera and Sasobit) on a construction project on the East Entrance Road of Yellowstone National Park. The mixtures were placed in August/September 2007. This report documents the results and summarizes the findings of this technology deployment.
17. Key Words WARM MIX ASPHALT (WMA), ADVERA, SASOBIT, YELLOWSTONE NATIONAL PARK, EAST ENTRANCE ROAD			18. Distribution Statement No restriction. This document is available to the public from the sponsoring agency at the website http://www.wfl.fhwa.dot.gov/td/.
19. Security Classif. (of this report) Unclassified		20. Security Classif. (of this page) Unclassified			21. No. of Pages 16	22. Price $0.00
