FHWA-WFL/TD-09-001
January 2009

Front Materials

• Cover
• Table of Contents
  • Figures
  • Tables
• Acronyms and Abbreviations



Technical Report Documentation Page

1. Report No. FHWA-WFL/TD-09-001	2. Government Accession No.			3. Recipient's Catalog No.
4. Title and Subtitle Best Management Practices for Chemical Treatment Systems for Construction Stormwater and Dewatering				5. Report Date January 2009
				6. Performing Organization Code
7. Author(s) Richard A. McLaughlin, Ph.D. and Alex Zimmerman, CPESC				8. Performing Organization Report No.
9. Performing Organization Name and Address North Carolina State University 101 Derieux Street, 2232 Williams Hall Raleigh, NC 27695				10. Work Unit No. (TRAIS)
				11. Contract or Grant No.
12. Sponsoring Agency Name and Address Federal Highway Administration Western Federal Lands Highway Division 610 East 5th St. Vancouver, WA 98661				13. Type of Report and Period Covered Final Report 2009
				14. Sponsoring Agency Code HFL-17
15. Supplementary Notes COTR: Amit Armstrong, Ph.D., P.E. This project was funded under the FHWA Federal Lands Highway Technology Deployment Initiatives and Partnership Program (TDIPP) and Coordinated Technology Implementation Program (CTIP).
16. Abstract Chemical treatment systems (CTS) are implemented in areas where traditional, physical erosion and sediment control practices will not meet water quality goals for construction site runoff. The purpose of CTS is to reduce the amount of suspended sediment which would be released using conventional erosion control systems. The primary mechanism is the introduction of chemical flocculants into runoff, resulting in a binding of the suspended clays and silts together into larger particles which settle more quickly or can be filtered from the stormwater. Flow control through CTS is of vital importance for the proper dosing of stormwater runoff. All normal hydrologic analyses must be done to insure that reasonable peak flows are accounted for along with typical flows from designed storm events. Once analysis is adequately addressed, then the project can deal with the complexities of design and dose rate requirements. The overall objectives of this book are twofold. First, it is designed to provide a technically credible basis for best management practices for the use of CTS for turbidity reduction on road construction projects. Secondly, it is designed to identify the most important variables to address when selecting chemical treatment best management practices for a particular site.
17. Key Words BEST MANAGEMENT PRACTICES, CHEMICAL TREATMENT SYSTEMS, STORMWATER, DEWATERING, WATER QUALITY, TURBIDITY			18. Distribution Statement No restriction. This document is available to the public from the sponsoring agency at the website https://flh.fhwa.dot.gov/.
19. Security Classif. (of this report) Unclassified		20. Security Classif. (of this page) Unclassified			21. No. of Pages 12	22. Price $0.00

Form DOT F 1700.7 (8-72) Reproduction of completed page authorized
